THERMAL 300
Energy-efficient and economical single-phase heat pump for hot water heating in air-water systems
- 258 liter hot water tank
- Corrosion protection using anode technology
- High-quality thermal insulation of the tank
- Option to connect additional heat sources
- Hot water heating using indoor or outdoor air as heat source
- 258 liter hot water tank
- Corrosion protection using anode technology
- High-quality thermal insulation of the tank
- Option to connect additional heat sources
- Hot water heating using indoor or outdoor air as heat source
PUMP FEATURES
After heating, hot water heating is the largest financial cost in the operating expenses of a building. Up to 70% of heat energy is heat obtained for free from the ambient air. This method is therefore easy on the household budget and the environment.
To provide optimal hot water heating, the THERMAL 300 heat pump extracts energy directly from either the air in the room where it is installed, from ventilation air, or from outside air. Adjacent rooms can also be air-conditioned and dehumidified using the cool outlet air. The heat pump can produce 850 liters of hot water at 55 °C in 24 hours.
The enameled surface of the hot water tank effectively protects against corrosion. It also comes equipped with a magnesium anode located in the middle of the tank.
DOWNLOAD
TECHNICAL PARAMETERS
| Type designation | x-change fresh 300 A I |
| Energy class |  |
| Rated thermal output (kW) | 1,40 |
| Coefficient of Performance (A20/W10-53) | 3,67 |
| Energy efficiency of water heating (%) | 151 |
| Technical features of the water tank | |
| Capacity (l) | 258 |
| Heat exchanger heat transfer surface (m²) | 1,00 |
| Amount of hot water per 24 hours (l/24hr) | 850 |
| Working range (primary energy source) (°C) | from -10 to +35 |
| Max. hot water temperature with heat pump (°C) | 62 |
| Electric heater output (kW) | 2,00 |
| Min. required indoor air volume (m³) | 3,60 |
| Sound power level according to EN ISO 9614-2 (dB) | 58,30 |
| Height / diameter (mm) | 1768 / 707 |
| Min. room height for maintenance and installation (mm) | 2100 |
| Weight (kg) | 153 |
| Country of origin | Germany |
| Order number | W20201 |
Easy assembly
The future in heating for its indisputable advantages of easy installation and universal use.
Heating capacity
Air-water heat pumps are characterised primarily by their high heating capacity and heating factor.
Quiet operation
Reliable operation even at extreme outdoor temperatures and very low noise levels.
